MPS-10Series Adjustable Linear DC Power Supply
- Voltage range: 0 – 60V, current range: 0 – 30A, power: 360W
- Display resolution of 10mV/1mA
- Panel lock function
- Output switch control
- Switching between high and low current levels
- Color screen display, multiple parameters are clear at a glance
Want a custom configuration?
The newly launched MPS – 10 Series Two – Channel DC Power Supply has diverse parameters: rated output voltage spans 0 – 30V to 0 – 100V, rated output current 0 – 0.5A to 0 – 10A, rated output power 50W to 300W. It features 10mV/1mA display resolution, CH2 with 1.8V/2.5V/3.3V/5V@3A, panel lock, output switch control, high/low current switching, and a clear color screen. Ideal for production line tests, lab research, electronic repair, and automated equipment integration.
| Model | Voltage | Current | Power |
|---|---|---|---|
| MPS-11 | 0~30V | 0~2A | 60W |
| MPS-12 | 0~30V | 0~4A | 120W |
| MPS-13 | 0~30V | 0~6A | 180W |
| MPS-14 | 0~30V | 0~8A | 240W |
| MPS-15 | 0~30V | 0~10A | 300W |
| MPS-16 | 0~60V | 0~2A | 120W |
| MPS-17 | 0~60V | 0~4A | 240W |
| MPS-18 | 0~80V | 0~2A | 160W |
| MPS-19 | 0~100V | 0~0.5A | 50W |
| Regulation | Load regulation | Voltage: 0.05%+5mV/8mV | Current: 0.1%+5mA/8mA |
| Line regulation rate | Voltage: 0.05%+5mV/8mV/10mV | Current: 0.1%+5mA/8mA | |
| Resolution | Setting resolution | Voltage: 10mV | Current: 1mA |
| Read back resolution | Voltage: 10mV | Current: 1mA | |
| Accuracy | Setting accuracy | Voltage: ≤0.1%+2-3digits | Current: ≤0.2%+3-6digits (25℃±5℃) |
| Read back accuracy | Voltage: ≤0.1%+2-3digits | Current: ≤0.2%+3-6digits (25℃±5℃) | |
| Signal Integrity | Ripple and noise | Voltage: 3-10mVrms | Current: 3-6mArms |
